Central não metálica de FRP/KFRP Rod que reforça a tecnologia de Pultruded da forma redonda do CSM Φ2.0
Detalhes do produto
material do kfrp
,Membro de FRP
Membro de força central não metálico CSM de FRP/KFRP Rod, KFRP Rod Φ2.0
Nós somos do membro de força central de FRP Rod fabricante não metálico/fornecedor em China, oferecendo o membro de força de Pultruded FRP Rod para cabos óticos da fibra.
Especificações: (FRP redondo: ∮0.4-∮5.0)
| Propriedade | Valores |
| Resistência à tração (Mpa) | ≥1100 |
| Módulo elástico (Gpa) | ≥50 |
| Força Flexural (Mpa) | ≥1100 |
| Módulo Flexural (Gpa) | ≥50 |
| Alongamento na ruptura (%) | ≤4 |
|
Coeficiente do thermal linear
expansão (- 30-80℃) (1/℃) |
<8*10-6 |
| Tolerância do diâmetro (milímetro) | ±2% |
| Raio de curvatura mínimo (milímetro) | 40*D |
| Densidade (g/cm3) | 2.05-2.15 |
| Teste de dobra de alta temperatura (50D, 100℃, 120h) |
Nenhum departamento, quebra e
ruptura |
| Teste de dobra da baixa temperatura (50D, - 40℃, 120h) |
Nenhum departamento, quebra e
ruptura |
| Torsão (±360°/m) | Não desintegrado |
We develop and produce Flat FRP strength member for different application.
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
Cable Strengthen Core For Fiber Optical Cables Non-Metallic FRP Rod Central Strength Member CSM Basic Info Technique: Pultrusion Type: Themosetting Plastic Profiles Diameter Ranges: 0.40 mm to 5.00 mm HS Code: 70199090 Materials: Resin, E-glass Fiberglass, Agents, etc. Applications: Central or peripheral strength member for fiber optical cables Origin: Jiangsu, China Product Description: Non-metallic FRP Rod strength member, usually located at the center or the periphery of
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
